| B系列產品 | |||
| 1 法國品牌，軍工品質,行業先進的大功率柴油發電機組 France brand,military quality。The most excellent superpower dieselgen-sets leading industry 3 卓越的啟動性能，為您的電源設備保駕護航 Superior starting performance,escorting your power equipment 5 采用電控高壓共軌技術，排放達到國III要求，具備擴展 國IV的能力 Adopting electric control high pressure common rail technology,achieving non-road emission stage III standard,possessing the ability of extending non-road emission stage iv standard 7獲得通信行業泰爾認證證書及第三方機組檢測報告 Obtain the TL certification of the communication industry and third party test report | 2 自主ECU核心技術，全面保證信息安全 Core-technology of self-developed ECU which guarantees information safety 4 高可靠性，超長大修期達32000h High reliability,super-long overhaul periof for 32000h 6 專業的發電機組應用集成能力 Professional application & integration capabilities for gen-sets | ||
| 機組型號Gensets Model | WPG2200B7 | WPG2475B7 | WPG2500B7 |
| 額定功率/容量(kW/kVA) Rated Power/Capacity | 1600/20000 | 1800/2250 | / |
| 備用功率/容量(kW/kVA) Standby Power/Capacity | 1760/2200 | 1980/2475 | 2000/2500 |
| 發動機型號Engine Model | 12M55D2000E310 | 12M55D2200E310 | 12M55D2200E310 |
| 額定功率(kW)Rated Power | 1390 | 1430 | 1500 |
| 備用功率（kW）Standby Power | 1527 | 1573 | 1650 |
| 氣缸數-缸徑×行程 Cylinder No.-Bore×Stroke | 12-180X215 | ||
| 排量（L）Displacement | 65.65 | ||
| 啟動方式Starting Method | DC24V電啟動 Electrical Starting | ||
| 調速方式Speed Governor | 電控ECU | ||
| 進氣方式Intake Way | 增壓中冷 Turbo & Inter-cooling | ||
| 機油容量(L)Oil Capacity | 480 | ||
| 冷卻液容量（L） Coolant Capacity | 650 | ||
| 經濟燃油消耗率(g/kW.h) Economic Fuel Consumption | 185 | ||
| 額定電壓（V）Rated Voltage | 400/230 | ||
| 頻率(Hz)Frequency | 50 | ||
| 額定電流(A)Rated Current | 2887 | 3248 | 3609 |
| 額定功率因數Rated Factor | 0.8（滯后lag） | ||
| 相數及接法 Phase No.& Connection | 三相四線，星型接法 3P4W,Y Style Connection | ||
| 調壓方式 Voltage Regulation Mode | 自動調壓AVR | ||
